Saintek Solar integrates mature processes with innovative tech, excelling in solar wafers. With precision slicing for low silicon use and high efficiency, it covers PERC, N-TOPCON and HJT technologies. Customizable specs cater to diverse needs, ensuring reliable performance for global clients.

N-type silicon Wafer

Size:182*183.75mm

Thickness:120±10μm

Oxygen content:≤11ppma

Size:182*183.75mm

Thickness:120±10μm

Oxygen content:≤11ppma

Intelligent TOPCON Solar Wafer Manufacturing

Characteristics of Saintek TOPCON Solar Wafer

Customized Silicon Wafers for Diverse Applications

Customized silicon wafers with unmatched precision are provided to meet clients’ specific needs.

Advanced Equipment with Established Processes

Silicon wafers are manufactured using a reliable process and advanced equipment for efficient production.

Low-Oxygen High-Temperature (LOHT) Manufacturing Process

The design addresses common defects in N-type silicon wafers, boosting efficiency and yield in TOPCon applications.

High lifetime

Higher than 70u which is better than the industry standard.

LEADING THE NEW PHOTOVOLTAIC ERA WITH SAINTEK

Know more about TOPCON or how to become Saintek’s partner.
